Vimar - 09961 - Frame 1M for DIN rail 53mm depth

09961
System infrastructure / Enclosures and control units / Switchboards / Shared accessories

Frame 1M for DIN rail 53mm depth
Mounting frame for DIN (60715 TH35) rail installation, 17,5 mm 1,5 modules sized, 53 mm depth, for 1 8000 standard module, RAL 7035 grey. Not suitable for 08065…

产品状态
3 - Active

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Snap mounting

Mounting method of the module inserts
Back side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
1,50

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
No

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
Yes

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

96. Electrotechnical expert

最小订单数量: 50 NR

条形码

8007352043787

1 NR

7x2.6x5.8 [cm]

21.6 [g]

8007352005921

50 NR

28.4x18.4x13.7 [cm]

1,234.15 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
