Vimar - 09679.13 - Plate 2 sideM techn.matt clay

09679.13
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Plate 2 sideM techn.matt clay
2-module side cover plate for 3-module mounting boxes, technopolymer, matt clay

产品状态
3 - Active

您可能也感兴趣

09613 - Frame 3M +screws

09623 - Mounting frame Plana/Neve+screws

图纸

PNG DXF

Class group
Domestic switching devices

Class
Cover frame for domestic switching devices

Number of units
2

Mounting direction
Horizontal and vertical

Number of units horizontal
2

Number of units vertical
1

Number of modules horizontal (module system)
2

Number of modules vertical (module system)
1

With mounting grid
Yes

Suitable for subfloor installation duct box
Yes

Suitable for wall duct
Yes

Suitable for built-in installation
Yes

Label space/information surface
Yes

Material
Plastic

Material quality
Thermoplastic

Surface protection
Lacquered

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7042

Transparent
No

With hinged lid
No

Type of fastening
Clamp mounting

Width
120,00 mm

Height
86,00 mm

Depth
9,00 mm

Built-in width
120,00 mm

00. CE Marking - EU

29. QCERT - Colombia

最小订单数量: 10 NR

条形码

8007352662162

1 NR

13x9x0.9 [cm]

12 [g]

8007352662179

10 NR

17.1x9.8x9.9 [cm]

131.78 [g]

8007352670532

360 NR

59x34.5x32.5 [cm]

4,844 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
