Vimar - 09677.23 - Plate 7M techn.matt titanium

09677.23
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Plate 7M techn.matt titanium
7-module cover plate for 7-module mounting boxes, technopolymer, matt titanium

产品状态
3 - Active

您可能也感兴趣

09617 - Frame 7M +screws

图纸

PNG DXF

Class group
Domestic switching devices

Class
Cover frame for domestic switching devices

Number of units
7

Mounting direction
Horizontal and vertical

Number of units horizontal
7

Number of units vertical
1

Number of modules horizontal (module system)
7

Number of modules vertical (module system)
1

With mounting grid
Yes

Suitable for subfloor installation duct box
Yes

Suitable for wall duct
Yes

Suitable for built-in installation
Yes

Label space/information surface
Yes

Material
Plastic

Material quality
Thermoplastic

Surface protection
Lacquered

Surface finishing
Matt

Colour
Titanium

RAL-number (similar)
7039

Transparent
No

With hinged lid
No

Type of fastening
Clamp mounting

Width
210,00 mm

Height
86,00 mm

Depth
8,40 mm

Built-in width
210,00 mm

00. CE Marking - EU

29. QCERT - Colombia

最小订单数量: 5 NR

条形码

8007352662476

1 NR

23x9x0.9 [cm]

24.71 [g]

8007352662483

5 NR

24.2x10.3x5.7 [cm]

176.6 [g]

8007352670464

175 NR

59.5x38.5x26.5 [cm]

6,901 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
