Plate 7M techn.matt clay - 09677.13

Pdf
Vimar - 09677.13 - Plate 7M techn.matt clay
Vimar - 09677.13 - Plate 7M techn.matt clay

09677.13
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Plate 7M techn.matt clay
7-module cover plate for 7-module mounting boxes, technopolymer, matt clay

产品状态
3 - Active

您可能也感兴趣

09617
09617 - Frame 7M +screws

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
7
Mounting direction
Horizontal and vertical
Number of units horizontal
7
Number of units vertical
1
Number of modules horizontal (module system)
7
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7042
Transparent
No
With hinged lid
No
Type of fastening
Clamp mounting
Width
210,00 mm
Height
86,00 mm
Depth
8,40 mm
Built-in width
210,00 mm

00. CE Marking - EU

29. QCERT - Colombia

最小订单数量: 5 NR

条形码

Barcode Qty 1 NR
8007352663336
1 NR
23x9x0.9 [cm]
25.33 [g]
Barcode Qty 5 NR
8007352663343
5 NR
24.2x10.3x5.7 [cm]
178.11 [g]
Barcode Qty 175 NR
8007352670433
175 NR
59.5x38.5x26.5 [cm]
6,953.85 [g]
