Vimar - 09671.02 - Plate 1centrM techn.ivory

09671.02
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Plate 1centrM techn.ivory
1-module central cover plate for 3-module mounting boxes, technopolymer, ivory

产品状态
3 - Active

您可能也感兴趣

09613 - Frame 3M +screws

09623 - Mounting frame Plana/Neve+screws

图纸

PNG DXF

Class group
Domestic switching devices

Class
Cover frame for domestic switching devices

Number of units
1

Mounting direction
Horizontal and vertical

Number of units horizontal
1

Number of units vertical
1

Number of modules horizontal (module system)
1

Number of modules vertical (module system)
1

With mounting grid
Yes

Suitable for subfloor installation duct box
Yes

Suitable for wall duct
Yes

Suitable for built-in installation
Yes

Label space/information surface
Yes

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
1013

Transparent
No

With hinged lid
No

Type of fastening
Clamp mounting

Width
120,00 mm

Height
86,00 mm

Depth
8,90 mm

Built-in width
120,00 mm

00. CE Marking - EU

29. QCERT - Colombia

最小订单数量: 10 NR

条形码

8007352662537

1 NR

13x9x0.9 [cm]

19.92 [g]

8007352662544

10 NR

17.1x9.8x9.9 [cm]

255.72 [g]

8007352669765

360 NR

59x34.5x32.5 [cm]

9,605.92 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
