Blank cover 3M techn.slate grey - 09670.03

Pdf
Vimar - 09670.03 - Blank cover 3M techn.slate grey
Vimar - 09670.03 - Blank cover 3M techn.slate grey

09670.03
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Blank cover 3M techn.slate grey
Blank cover plate for 3-module mounting boxes, technopolymer, slate grey

产品状态
3 - Active

您可能也感兴趣

09613
09613 - Frame 3M +screws
09623
09623 - Mounting frame Plana/Neve+screws

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
3
Mounting direction
Horizontal and vertical
Number of units horizontal
3
Number of units vertical
1
Number of modules horizontal (module system)
3
Number of modules vertical (module system)
0
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Glossy
Colour
Grey
RAL-number (similar)
7043
Transparent
No
With hinged lid
No
Type of fastening
Clamp mounting
Width
120,00 mm
Height
86,00 mm
Depth
9,80 mm
Built-in width
120,00 mm

00. CE Marking - EU

29. QCERT - Colombia

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352661400
1 NR
13x9x0.9 [cm]
21.9 [g]
Barcode Qty 10 NR
8007352661417
10 NR
17.1x9.8x9.9 [cm]
273.2 [g]
Barcode Qty 360 NR
8007352706378
360 NR
59x34.5x32.5 [cm]
10,585.2 [g]
