Vimar - 09668.24 - Plate 8M(2+2+2+2)x71techn.matt copper
Vimar - 09668.24 - Plate 8M(2+2+2+2)x71techn.matt copper

09668.24
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Plate 8M(2+2+2+2)x71techn.matt copper
8-module cover plate (2+2+2+2, distance between centres 71 mm), technopolymer, matt copper

产品状态
3 - Active

您可能也感兴趣

09602.1
09602.1 - Frame 2M +claws 71mm
09603.1
09603.1 - Frame 2M wihtout screws 71mm

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
6
Mounting direction
Horizontal and vertical
Number of units horizontal
4
Number of units vertical
1
Number of modules horizontal (module system)
4
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Copper
RAL-number (similar)
8029
Transparent
No
With hinged lid
No
Type of fastening
Clamp mounting
Width
299,00 mm
Height
86,00 mm
Depth
8,50 mm
Built-in width
299,00 mm

00. CE Marking - EU

29. QCERT - Colombia

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352661349
1 NR
32x9x0.5 [cm]
38.7 [g]
Barcode Qty 5 NR
8007352661356
5 NR
10x4.5x35 [cm]
264 [g]
Barcode Qty 160 NR
8007352706354
160 NR
59x38.5x30 [cm]
9,198 [g]
