Plate 6M (2+2+2)x71 techn.matt silver

Pdf

Vimar - 09666.21 - Plate 6M (2+2+2)x71 techn.matt silver

09666.21
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Plate 6M (2+2+2)x71 techn.matt silver
6-module cover plate (2+2+2, distance between centres 71 mm), technopolymer, matt silver

产品状态
3 - Active

您可能也感兴趣

09602.1 - Frame 2M +claws 71mm

09603.1 - Frame 2M wihtout screws 71mm

图纸

PNG DXF

Class group
Domestic switching devices

Class
Cover frame for domestic switching devices

Number of units
6

Mounting direction
Horizontal and vertical

Number of units horizontal
3

Number of units vertical
1

Number of modules horizontal (module system)
3

Number of modules vertical (module system)
1

With mounting grid
Yes

Suitable for subfloor installation duct box
Yes

Suitable for wall duct
Yes

Suitable for built-in installation
Yes

Label space/information surface
Yes

Material
Plastic

Material quality
Thermoplastic

Surface protection
Lacquered

Surface finishing
Matt

Colour
Silver

RAL-number (similar)
9006

Transparent
No

With hinged lid
No

Type of fastening
Clamp mounting

Width
224,00 mm

Height
86,00 mm

Depth
8,50 mm

Built-in width
224,00 mm

00. CE Marking - EU

29. QCERT - Colombia

最小订单数量: 5 NR

条形码

8007352660540

1 NR

25x9x0.5 [cm]

33.07 [g]

8007352660557

5 NR

10x4.5x29 [cm]

205 [g]

8007352706200

190 NR

59.5x38.5x26.5 [cm]

7,790 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
