Plate 2M techn.black - 09662.04

Pdf
Vimar - 09662.04 - Plate 2M techn.black
Vimar - 09662.04 - Plate 2M techn.black

09662.04
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Plate 2M techn.black
2-module cover plate, technopolymer, black

产品状态
3 - Active

您可能也感兴趣

09602.1
09602.1 - Frame 2M +claws 71mm
09603.1
09603.1 - Frame 2M wihtout screws 71mm

图纸

PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
2
Mounting direction
Horizontal and vertical
Number of units horizontal
2
Number of units vertical
1
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Glossy
Colour
Black
RAL-number (similar)
9005
Transparent
No
With hinged lid
No
Type of fastening
Clamp mounting
Width
86,00 mm
Height
86,00 mm
Depth
8,60 mm
Built-in width
86,00 mm

00. CE Marking - EU

29. QCERT - Colombia

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352660915
1 NR
10x9x0.5 [cm]
13.04 [g]
Barcode Qty 10 NR
8007352660922
10 NR
14.1x9.8x9.9 [cm]
177.7 [g]
Barcode Qty 160 NR
8007352669987
160 NR
39x29.5x22 [cm]
3,333.2 [g]
