IoT dial thermostat 2M white - 09473

Pdf

Vimar - 09473 - IoT dial thermostat 2M white

09473
Wiring devices / View Wireless wiring devices / NEVE UP / Devices

IoT dial thermostat 2M white
Dial thermostat for ambient temperature control, 5(2) A 240 V~ relay output, View Wireless technology on Bluetooth® wireless technology 5.0 for mesh View Wireless system realization, 1 input for outer temperature sensor, supply voltage 100-240 V~ 50/60 Hz, heating and air-conditioning ON/OFF and PID, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, white LED backlighting and brightness regulation, supply voltage 100-240 V 50/60 Hz, white - 2 modules

产品状态
3 - Active

单, 说明书, 文档

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Stats, switches and controllers

Class
Room thermostat

Model
Other

Type of power supply
230 V AC

Connection
3-/4-wire

With receiver
No

External sensor
Yes

Thermal feedback
Parallel

Control characteristic
PID

Suitable for heating
Yes

Number of heater outputs
1

Number of cooler outputs
1

Adjustable differential
Yes

Temperature readable
Yes

With sound indicator
No

Sensor/feeler type
Other

Mounting method
Other

Number of modules (module system)
2

With display
Yes

Operation
Turn

With tap water circuit
No

Max. contact voltage
240 V

Max. contact load
5 A

Degree of protection (IP)
IP30

Explosion-proof
No

Colour
White

RAL-number
9003

Height
47,00 mm

Width
44,80 mm

Depth
41,50 mm

Class of the temperature control
IV

00. CE Marking - EU

00. CE Marking - EU

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352671386

1 NR

5.7x5.3x7.7 [cm]

87 [g]

8007352746534

60 NR

37.5x30x13.5 [cm]

5,580 [g]
