Vimar - 09330 - 2P 6A 24V SELV outlet white

09330
Wiring devices / Traditional wiring devices / NEVE UP / Devices

2P 6A 24V SELV outlet white
2P 6 A 24 V (SELV) socket outlet for plug 01620 (pins ø 3 mm, distance between centres 12,4 mm), white. For auxiliary circuits.

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Socket outlet

With hinged lid
No

Label space/information surface
Yes

Colour
White

RAL-number (similar)
9003

Metallic colour
No

Transparent
No

Lockable
No

Eject-mechanism
No

Insulated mounting
No

Mounting method
Flush-mounted

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

With loop through function
No

Rotated central insert
No

Nominal current
6 A

Nominal voltage
24 V

Device width
22,30 mm

Device height
47,00 mm

Device depth
34,50 mm

00. CE Marking - EU

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352296534

1 NR

4.1x2.8x5.3 [cm]

22.73 [g]

8007352296541

10 NR

14.4x9x6 [cm]

262.33 [g]

8007352296558

160 NR

37.5x30x13.5 [cm]

4,576.67 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
