Vimar - 09062 - Two interlocked 1P NO+NO 10A pushes w

09062
Wiring devices / Traditional wiring devices / NEVE UP / Devices

Two interlocked 1P NO+NO 10A pushes w
Two 1P NO + 1P NO 10 A 250 V~ interlocked push buttons, with directional arrows, white

产品状态
3 - Active

您可能也感兴趣

09060 - 2P 10AX switch white

图纸

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Other

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
100

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

With lighting
No

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
22,30 mm

Device height
47,00 mm

Device depth
43,00 mm

00. CE Marking - EU

07. INGCER - Chile

13. SNI-MGI - Indonesia

15. CCC - China

19. NOM - Mexico

29. QCERT - Colombia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352416741

1 NR

4.1x2.8x5.3 [cm]

31.8 [g]

8007352416758

20 NR

21.4x11.6x6 [cm]

691.2 [g]

8007352665781

200 NR

30.5x25.5x22.5 [cm]

7,255 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
