Vimar - 09005.CM - 1P 16AX 2-way switch carbon matt

09005.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

1P 16AX 2-way switch carbon matt
1P 16 AX 250 V~ 2-way switch, Carbon Matt. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

09005.2.CM - 1P 16AX 2-way switch 2M carbon matt

09001.CM - 1P 16AX 1-way switch carbon matt

09013.CM - 1P 16AX reversing switch carbon matt

09008.CM - 1P NO 10A push button carbon matt

图纸

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Two-way switch

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Surface protection
Lacquered

Surface finishing
Matt

Colour
Anthracite

RAL-number (similar)
7016

Label space/information surface
Yes

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Nominal voltage
250 V

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Device width
22,50 mm

Device height
47,00 mm

Device depth
35,90 mm

Built-in depth
23,10 mm

00. CE Marking - EU

13. SNI - Indonesia

15. CCC - China

29. QCERT - Colombia

37. Marking - Morocco

99. WEEE Directive

最小订单数量: 50 NR

条形码

8007352657762

1 NR

4.1x2.8x5.3 [cm]

25.6 [g]

8007352657779

50 NR

21.4x11.6x14.2 [cm]

1,370.8 [g]

8007352657786

500 NR

57.5x22x29.5 [cm]

13,834 [g]
