1P 16AX 1-way switch white - 09001

Pdf

Vimar - 09001 - 1P 16AX 1-way switch white

09001
Wiring devices / Traditional wiring devices / NEVE UP / Devices

1P 16AX 1-way switch white
1P 16 AX 250 V~ 1-way switch, white. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

09001.2 - 1P 16AX 1-way switch 2M white

09015 - 2P 16AX 1-way switch white

09005 - 1P 16AX 2-way switch white

09013 - 1P 16AX reversing switch white

09008 - 1P NO 10A push button white

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Off switch 1-pole

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Device width
22,30 mm

Device height
47,00 mm

Device depth
35,90 mm

Built-in depth
23,10 mm

00. CE Marking - EU

07. INGCER - Chile

13. SNI-MGI - Indonesia

15. CCC - China

19. NOM - Mexico

29. QCERT - Colombia

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

8007352296145

1 NR

4.1x2.8x5.3 [cm]

23.4 [g]

8007352296152

50 NR

21.4x11.6x14.2 [cm]

1,250.8 [g]

8007352296169

500 NR

57.5x22x29.5 [cm]

12,888.67 [g]
