1P 10AX 2-way switch luminous
1P 10 AX 250V~ 2-way switch, luminous, for signalling unit. Provided without signalling unit. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
22,00 mm
Device height
50,10 mm
Device depth
35,50 mm
Built-in depth
24,00 mm

00. CE Marking - EU

37. Marking - Morocco

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352078086
1 NR
4.1x2.8x5.3 [cm]
25.4 [g]
Barcode Qty 50 NR
8007352078093
50 NR
21.4x11.6x14.2 [cm]
1,365.2 [g]
