By-alarm Plus RF repeater - 03840

Pdf

03840
Safety / By-alarm Plus / Surface mounting components / Non-modular components

By-alarm Plus RF repeater
By-alarm Plus repeater, 868 MHz radio frequency connection, 12 VDC power supply, extends the radio coverage area without the need for a wired connection to the control unit, 2 antennas for horizontal and vertical polarisation with antenna-diversity, 4 AA 1.5V alkaline batteries included, plastic enclosure

产品状态
3 - Active

Class group
Installation bus systems
Class
Repeater for bus system
Mounting method
Other

00. CE Marking - EU

37. Marking - Morocco

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352708709
1 NR
15.9x14.1x3.9 [cm]
291.8 [g]
Barcode Qty 12 NR
8007352708723
12 NR
29.5x23.5x17.5 [cm]
3,760 [g]

分享

Codice QR scheda articolo

合法

Vimar保留随时修改所示产品的特性的权利,恕不另行通知。 安装必须由符合资质的人员执行,严格遵守所在国家现行的电气材料安装相关规定。 有关产品卡信息的使用条件,请参阅 使用条件
