03802
Safety / By-alarm Plus / Surface mounting components / Non-modular components
By-alarm Plus 125 zones circuit board
By-alarm Plus programmable control unit with keypad and display, 13.8 VDC power supply, 10 local In/Out zones extendable to 125 with expansions (modules or boards), 3 programmable 12 VDC outputs, 1 programmable relay output, 2 programmable open-collector outputs
产品状态
3 - Active
单, 说明书, 文档
- Feuille d’instructions (196 kb)
- Anwendungshinweise (197 kb)
- Multilanguage instructions sheet (283 kb)
- Manuel d’installation (1682 kb)
- Installation Manual (1669 kb)
- Installationsanleitung (1684 kb)
- Manuale installazione (1681 kb)
- Manuel de l'utilisateur (2821 kb)
- Bedienungsanleitung (2823 kb)
- Multilanguage user manual (5054 kb)
产品配套软件
图纸
Class group
Alarm installations, emergency call and signalling
Alarm installations, emergency call and signalling
Class
Central alarm panel for intrusion detection system
Central alarm panel for intrusion detection system
Number of detection groups
125
125
Integrated dial device
No
No
Number of outputs for acoustic signal generators
1
1
Number of outputs for optical signal generators
3
3
Occurrence memory
Yes
Yes
Operating voltage
13 V
13 V
Suitable for bus connection
Yes
Yes
Radio connection
Yes
Yes
With power adaptor
No
No
Emergency power supply integrated
Yes
Yes
Interface external
Yes
Yes
Height
9.000,00 mm
9.000,00 mm
Width
16.000,00 mm
16.000,00 mm
Depth
2.300,00 mm
2.300,00 mm
Compatible with Apple HomeKit
No
No
Compatible with Google Assistant
No
No
Compatible with Amazon Alexa
No
No
IFTTT support available
No
No
VdS class
None
None
最小订单数量: 1 NR
条形码
8007352707245
1 NR
17x11x5.5 [cm]
192.93 [g]
8007352707252
10 NR
29.5x23.5x17.5 [cm]
2,199 [g]
