Vimar - 02972 - Dial thermostat KNX 2M grey

02972
Smart systems&products / KNX / Shared components / Devices

Dial thermostat KNX 2M grey
Rotary dial thermostat for room temperature control (heating and air conditioning), for KNX automation, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, can be interfaced with KNX actuator with proportional analogue outputs to realize a class V modulating room thermostat (contribution 3%), 1 input for electronic temperature sensor 20432, 19432 or 14432 or wired temperature sensor 02965.1, 1 programmable digital input, white LED backlighting, grey - 2 modules. To be completed with Eikon, Arké and Plana cover plates, for Idea with dedicated mounting frame 16723

产品状态
3 - Active

单, 说明书, 文档

产品配套软件

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Stats, switches and controllers

Class
Room thermostat

Model
Other

Connection
2-wire

With receiver
No

External sensor
Yes

Thermal feedback
Parallel

Control characteristic
PID

Suitable for heating
Yes

Number of heater outputs
1

Number of cooler outputs
1

Adjustable differential
Yes

Temperature readable
Yes

With sound indicator
No

Sensor/feeler type
Resistance sensor

Mounting method
Flush-mounted

Number of modules (module system)
2

With display
Yes

Operation
Turn

With tap water circuit
No

Max. contact voltage
29 V

Max. contact load
0 A

Degree of protection (IP)
IP20

Explosion-proof
Yes

Colour
Grey

RAL-number
7024

Height
49,00 mm

Width
44,80 mm

Depth
41,50 mm

Diameter
0 mm

Class of the temperature control
V

00. CE Marking - EU

37. Marking - Morocco

46. UK PSTI compliance

92. RoHS UAE

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352668416

1 NR

5.7x5.3x7.7 [cm]

74.38 [g]

8007352746428

60 NR

37.5x30x13.5 [cm]

4,796.52 [g]

8007352668423

70 NR

39.5x30x17 [cm]

5,596 [g]
