LED emergency lamp 230V Eikon Evo 7M - 02661

Pdf
Vimar - 02661 - LED emergency lamp 230V Eikon Evo 7M
Vimar - 02661 - LED emergency lamp 230V Eikon Evo 7M

02661
Wiring devices / Traditional wiring devices / EIKON / Devices

LED emergency lamp 230V Eikon Evo 7M
Emergency lighting device with high-efficiency LED, supply voltage 230 V~ 50-60 Hz, rechargeable Ni-Cd battery, built-in mounting frame for 6/7-module flush mounting boxes. To complete with Eikon Evo cover plate

产品状态
3 - Active

Class group
Luminaires
Class
Emergency luminaire
Monitoring equipment
None
With remote switch connection
Yes
Power supply system
Peripheral (individual battery)
Battery quality
NiCd
Lamp type
LED not exchangeable
With light source
Yes
Housing colour
White
Voltage type
AC
Nominal voltage
230,00 - 230,01 V
Degree of protection (IP)
IP40
Protection class
II
Max. system power
5,00 W
Rated luminous flux according to IEC 62722-2-1
75
Width
73,00 mm
Height/depth
72,50 mm
Length
197,00 mm
Built-in width
197,00 mm
Built-in height/depth
44,70 mm

00. CE Marking - EU

17. ENEC 03 (IMQ)

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352424159
1 NR
22.5x9.7x10 [cm]
393.5 [g]
