MASTER dimmer 120V MARINE - 01985.120

Pdf
Vimar - 01985.120 - MASTER dimmer 120V MARINE
Vimar - 01985.120 - MASTER dimmer 120V MARINE

01985.120
Smart systems&products / By-me Plus / Shared components / DIN devices

MASTER dimmer 120V MARINE
MASTER dimmer, 120 V~ 60 Hz for: 40-500 W incandescent lamps , 40-300 W electronic transformers, 10-200 W CFL lamps, 3-200 W LED lamps, LED electronic transformers, for DIN (60715 TH35) rail installation, occupies 4 17,5 mm modules. For MARINE sector

产品状态
2 - Will be discontinued

Class group
Installation bus systems
Class
Dimming actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Model
Dimming actuator
Width in number of modular spacings
4
With bus connection
Yes
Bus module detachable
No
Local operation/hand operation
No
With LED indication
Yes
Number of outputs
1
Output power
40 - 500 W
Power boost suitable
No
Type of load
Universal and LED Retrofit
Voltage
120,00 - 120,01 V
Parallel-service possible
No
Frequency
60,00 - 60,01 HZ
Degree of protection (IP)
IP20

37. Marking - Morocco

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352487864
1 NR
11.7x10.8x7.1 [cm]
224.4 [g]
