MASTER dimmer 230V 700VA - 01865

Pdf
Vimar - 01865 - MASTER dimmer 230V 700VA
Vimar - 01865 - MASTER dimmer 230V 700VA

01865
Smart systems&products / By-me Plus / Shared components / DIN devices

MASTER dimmer 230V 700VA
Dimmer, 230 V~ 50/60 Hz for: 40-700 VA dimmable electronic transformers, with neutral terminal, MASTER function for 01866, protection fuse, MOSFET technology, for DIN (60715 TH35) rail installation, occupies 4 17,5 mm modules

产品状态
2 - Will be discontinued

Class group
Installation bus systems
Class
Dimming actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Model
Dimming actuator
Mounting method
Other
Width in number of modular spacings
4
With bus connection
Yes
Bus module detachable
No
Local operation/hand operation
No
With LED indication
Yes
Number of outputs
1
Power boost suitable
No
Type of load
Universal
Voltage
230,00 - 230,01 V
Parallel-service possible
No
Frequency
50,00 - 60,00 HZ
Degree of protection (IP)
IP20

00. CE Marking - EU

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352387461
1 NR
11.7x10.8x7.1 [cm]
210 [g]
