01742
Safety / By-alarm Plus / Surface mounting components / Non-modular components
By-alarm Plus DT IP55 volum.surf.detect.
By-alarm Plus passive infrared and microwave dual technology detector, with anti-blinding, 120° coverage up to 12m, high (2.2-2.7 metres) or low (0.8-1.2 metres) mounting, can be set for PET immunity, IP55, 1 NO and NC 28 VDC 0.1 A relay output, 9.5-16 VDC power supply with 30 mA 12V, surface mounting, for outdoor use
产品状态
3 - Active
Class group
Alarm installations, emergency call and signalling
Alarm installations, emergency call and signalling
Class
Movement detector for danger detection system
Movement detector for danger detection system
Type of messaging
Infrared/microwave (Dual)
Infrared/microwave (Dual)
Mounting method
Surface mounting
Surface mounting
Monitoring radius
120 m
120 m
Detection range
12
12
Operating current
30,00 mA
30,00 mA
Height
144,50 mm
144,50 mm
Width
78,00 mm
78,00 mm
Depth
59,00 mm
59,00 mm
Characteristic
Distance
Distance
Recommended mounting height
2450,00 mm
2450,00 mm
Cover monitoring
Yes
Yes
Radio system
No
No
Colour
White
White
VdS class
None
None
最小订单数量: 1 NR
条形码
8007352767386
1 NR
15.7x8.1x10 [cm]
245 [g]
