4-analog-outputs actuator KNX - 01536

Pdf
Vimar - 01536 - 4-analog-outputs actuator KNX
Vimar - 01536 - 4-analog-outputs actuator KNX

01536
Smart systems&products / KNX / Shared components / DIN devices

4-analog-outputs actuator KNX
Actuator with 4 analogue 0-10V or (0)4-20 mA outputs, KNX standard, installation on DIN rail (60715 TH35), occupies 4 modules size 17.5 mm

产品状态
3 - Active

Class group
Installation bus systems
Class
Analogue actuator for bus system
Bus system KNX
Yes
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Mounting method
Other
Width in number of modular spacings
4
Model
Base module
With LED indication
No
With bus connection
Yes
Number of outputs
4
Output voltage
0 - 10 V
Degree of protection (IP)
IP20

00. CE Marking - EU

27. KNX

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352561441
1 NR
9.3x7.8x6.5 [cm]
194.5 [g]
Barcode Qty 11 NR
8007352762244
11 NR
40x37x8 [cm]
2,337.5 [g]
