Solenoid valve actuator 6 out 230V KNX - 01535

Pdf
Vimar - 01535 - Solenoid valve actuator 6 out 230V KNX
Vimar - 01535 - Solenoid valve actuator 6 out 230V KNX

01535
Smart systems&products / KNX / Shared components / DIN devices

Solenoid valve actuator 6 out 230V KNX
Actuator for solenoid valves, 6 (six) 230 V~ 0.5 A outputs, push buttons for local control, KNX standard, installation on DIN rail (60715 TH35), occupies 4 modules size 17.5 mm

产品状态
3 - Active

Class group
Installation bus systems
Class
Heating actuator for bus system
Bus system KNX
Yes
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Radio frequent bidirectional
No
Mounting method
Other
Width in number of modular spacings
4
With bus connection
Yes
Correcting variable consistent
No
Valve protection function
Yes
Manual switch
Yes
Max. switching current (resistive load)
0,50 A
Number of outputs
6
Max. output current
0,75 A
Switching voltage
24,00 - 230,00 V
Degree of protection (IP)
IP20

00. CE Marking - EU

27. KNX

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352561434
1 NR
9.3x7.8x6.5 [cm]
169.5 [g]
Barcode Qty 11 NR
8007352762206
11 NR
40x37x8 [cm]
2,062.5 [g]
