KNX 2 roller blinds actuator - 01524

Pdf
Vimar - 01524 - KNX 2 roller blinds actuator
Foto gallery #1
Foto gallery #2
Vimar - 01524 - KNX 2 roller blinds actuator

01524
Smart systems&products / KNX / Shared components / DIN devices

KNX 2 roller blinds actuator
Actuator for 2 roller shutters, cosφ 0.6 3,5 A 250 V~ motor relay outputs, KNX standard, installation on DIN rail (60715 TH35), occupies 4 17,5 mm modules

产品状态
2 - Will be discontinued

其他可选产品

01523.1
01523.1 - 250V 16A 4-output actuator KNX
Class group
Installation bus systems
Class
Shutting actuator for bus system
Bus system KNX
Yes
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Radio frequent bidirectional
No
Mounting method
Other
Width in number of modular spacings
4
With bus connection
Yes
Bus module detachable
No
Local operation/hand operation
Yes
With LED indication
Yes
Number of inputs
0
Switching current (resistive)
16 A
Max. number of venetian-blind outputs
2
With switch function
Yes
Type of current
AC
Degree of protection (IP)
IP20

00. CE Marking - EU

27. KNX

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352383593
1 NR
11.7x10.8x7.1 [cm]
254.1 [g]
