Home automation module 3IN 3OUT LED - 01475

Pdf
Vimar - 01475 - Home automation module 3IN 3OUT LED
Foto gallery #1
Foto gallery #2
Vimar - 01475 - Home automation module 3IN 3OUT LED

01475
Smart systems&products / By-me Plus / Shared components / Non-modular components

Home automation module 3IN 3OUT LED
Module with 3 programmable digital inputs for contacts without potential, 3 LED control outputs, By-me home automation, flush mounting at the back of the device

产品状态
3 - Active

Class group
Installation bus systems
Class
Basic module for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Mounting method
DRA (DIN-rail adapter)
Width in number of modular spacings
0
Local operation/hand operation
No
Number of inputs
3
Number of outputs
3
Degree of protection (IP)
IP20
With bus connection
Yes

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

46. UK PSTI compliance

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352539433
1 NR
5.7x5.3x7.7 [cm]
38.2 [g]
Barcode Qty 70 NR
8007352733169
70 NR
39.5x30x17 [cm]
3,012 [g]
问题： If retrofitted, can the lighting of a group of lamps via push button/traditional 1-way switch be transferred onto the By-me bus?
回答： Product art. 01475 can receive the voltage-free contact from a traditional control in input (both a push button and a 1-way switch, simply specify the related option during configuration) and propagate the control towards the home automation system actuator to which the load to manage is connected on the By-me home automation system BUS.
