![Vimar - 00750 - 1P 2[32]A 1-way push button switch](https://www.vimar.com/irj/go/km/docs/z_catalogo/MAIN_IMAGE/00750-vimar-componenti-illuminazione-interruttore-a-pulsante-1p-2-32-a.56508.jpg)
00750
Portable installation / Lighting components / Portable controls / Portable push buttons
1P 2[32]A 1-way push button switch
1P 2[32] A 250 V~ 1-way push button-operated switch, 8 mm, mounted ring
产品状态
3 - Active
Class group
Domestic switching devices
Domestic switching devices
Class
Device built-in switch and -push button
Device built-in switch and -push button
Model
Combination switch/button
Combination switch/button
Method of operation
Push button
Push button
Number of control elements
1
1
Connection type
Screwed terminal
Screwed terminal
Number of poles
1-pole
1-pole
Type of fastening
Fastening ring/-nut
Fastening ring/-nut
Hole diameter built-in
0 - 10 mm
0 - 10 mm
Built-in depth
10 mm
10 mm
Illumination
None
None
Imprint/indication
None
None
Nominal voltage
250 V
250 V
Nominal current
2,00 A
2,00 A
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Transparent
No
No
Colour control elements
White
White
RAL-number (similar) control element
9003
9003
Housing colour
Black
Black
RAL-number (similar) housing
9005
9005
00. CE Marking - EU
37. Marking - Morocco
最小订单数量: 250 NR
条形码
8007352035201
1 NR
2.3x2.8x1.3 [cm]
4.6 [g]
8007352006577
250 NR
19x19x11 [cm]
1,335.53 [g]
