VIMAR handfree S.S. voice unit interface - 6560

Pdf

6560
ELVOX Door entry system / Multi-wire video entry system / Shared A/V components / System components

VIMAR handfree S.S. voice unit interface
Module for Sound System 0931 and 6680 power supply unit audio interfacing with VIMAR speakerphone interphones, power supply 15-21 Vd.c., installation on DIN rail (60715 TH35), occupies 4 modules size 17.5 mm

产品状态
9 - Discontinued

问题: Is the 6560 Speakerphone also used for the Elvox DigiBUS and Due Fili video door entry modules?
回答: No, it is only required for Sound System technology with intercoms (part no. 20555 - 20555.N - 20555.B - 14555 - 14555.SL).
问题: What is the 6560 Speakerphone and what is it for? Does it always have to be installed with the Vimar intercom in Sound System?
回答: The ELVOX part no. 6560 serves to integrate Vimar Intercoms (part no. 20555 - 20555.N - 20555.B - 14555 - 14555.SL) in Sound System and should be installed as close as possible to the Elvox power supply, connecting it according to the wiring schemes provided and upstream of the other devices installed.
