01913
Smart systems&products / Smart climate control / Surface mounting components / Non-modular components
GSM timer-thermostat 120-230V white
Electronic timer-thermostat for local or remote ON/OFF control (via SMS or dedicated app) of the ambient temperature (heating and air-conditioning) with built-in GSM phone dialler, daily/weekly programming, class I temperature control device (contribution 1%), change-over relay output 5(2) A 230 V~, an additional output and a digital input, remote control via SMS, 120-230 V~ power supply, surface mounting, white
产品状态
9 - Discontinued
图纸
| 问题： | How is the 01913 Clima-phone powered? |
|---|---|
| 回答： | The device is normally powered via the mains voltage (terminals L and N), which may be either 120V to 230V; it also has rechargeable batteries (provided) inside the device to ensure function in the absence of mains voltage. |
| 问题： | What happens when the batteries are connected the wrong way or if they are not present? |
| 回答： | The display shows 2 flashing icons: the ˝battery˝ symbol and a ˝warning˝ symbol, the latter represented by a triangle with an exclamation mark inside. The flashing will persist until the situation is rectified with both batteries charged and inserted correctly. As long as this situation of misplaced/missing batteries persists, Clima-phone part no. 01913 will continue to perform all of its functions, however, in case of a power outage, it will shut down immediately, disabling the outputs (relays and auxiliary output). |
| 问题： | What happens after a power failure and batteries have run out? |
| 回答： | During a power outage, the 01913 timer-thermostat initially maintains full operation (with GSM module functional) for about two hours if the batteries are fully charged. During this period, the display will show the ˝battery˝ symbol (which does not indicate the charge remaining on the batteries). When the batteries finally drop to a charge level that cannot ensure the proper functioning of the GSM, the GSM module is turned off and the outputs (relay and auxiliary output) are deactivated. To warn of this impending event, the whole display starts flashing a few minutes prior to its implementation. If the mains power does not return, the 01913 timer-thermostat continues to display the room temperature and time for about an hour before switching off completely. The times are approximate, since some operating conditions (GSM signal level, relay activation ...) may affect actual consumption of the 01913 timer-thermostat and thus the duration of the batteries. In any case, all settings are kept even when the thermostat switches off completely (the data is saved in non volatile memory) and the time setting remains for a few days. When the mains voltage returns, the device automatically resumes correct function, applying the settings and config |
| 问题： | Is it possible to insert an external antenna on the 01913 Clima-phone to increase reception? |
| 回答： | No, you can't add an external antenna. |
| 问题： | Is it possible to control boiler via radio (as with the Clima-phone system)? |
| 回答： | It is not possible, the two systems are not compatible. Clima-phone only allows you to control the boiler via cable. |
| 问题： | What are the electrical characteristics of the input, the auxiliary output and the control relay of the boiler? |
| 回答： | The auxiliary output has the following characteristics:V=120/230 VAC, I=100mA. It is a dedicated TRIAC output for driving an auxiliary relay with coil voltage 120/230 VAC.The auxiliary input is a digital high impedance input and only works with AC voltage (120/230 VAC) The control output is a dry contact relay switch with the following characteristics: V=250 V ; I=5(2) A |
| 问题： | What is the function of the terminals IN and N? |
| 回答： | Terminals IN and N correspond to the 120-230 VAC digital auxiliary input (for Technical alerts) |
| 问题： | What is the function of terminals L and 1? |
| 回答： | Terminals L and 1 correspond to the TRIAC auxiliary output (100mA 120-230 VAC) for the control of an auxiliary relay connected to a generic load |
| 问题： | What are the NO-C-NC terminals? |
| 回答： | These terminals are associated with the power relay dedicated to the control of the pump, burner, timer valve, etc… |
| 问题： | Is it possible to receive alerts locally via telephone calls? |
| 回答： | Answer responses are only sent via SMS messages, not calls. |
| 问题： | Does the Clima-phone part no. 01913 have a voice menu? |
| 回答： | No, the Clima-phone can be configured, controlled and queried only via SMS or via EasyTool software version 2.0 or higher (with 01998.S interface). |
| 问题： | What type of SIM do you recommend? |
| 回答： | In order to identify a SIM card that is definitely compatible with our product, please refer to the indications we usually provide regarding the characteristics of the recommended SIM, which are as follows: - The related operator must be chosen among the leading providers, i.e. Tim, Vodafone and Wind; - The related SIM blocking PIN must be disabled. - It must be set to operate solely with the 2G network (GSM); - Its data network must be completely deactivated: indeed, the contract must be of the ˝Voice+SMS” type; - Possibly with a different rate plan than a rechargeable one, to avoid running out of credit by accident. |
| 问题： | The timer-thermostat doesn’t answer the SMS messages sent despite there being sufficient credit. |
| 回答： | Perform the following checks in sequence: 1. As regards the SIM to be used in the device, we normally recommend that it has the following characteristics: a. The related operator must be chosen among the leading providers, i.e. Tim, Vodafone and Wind; b. The related SIM blocking PIN must be disabled. c. It must be set to operate solely with the 2G network (GSM); d. Its data network must be completely deactivated: indeed, the contract must be of the “Voice+SMS” type; e. Possibly with a different rate plan than a rechargeable one, to avoid running out of credit by accident. 2. Restart the product, according to the procedures set out below: - Disconnect the power from the product in question; - Remove the SIM from inside it; - Insert it in a mobile phone and delete all the SMS messages present in the memory of the SIM itself; - Re-install the SIM in the device while it remains unpowered; - Re-apply power to the product; - Send the SMS message: ˝user-code˝.C1.STATUS (e.g.: 1234.C1.STATUS) and check its operation. |
