IP56 junction box 240x190x90mm - V55208

Pdf
Vimar - V55208 - IP56 junction box 240x190x90mm
Vimar - V55208 - IP56 junction box 240x190x90mm

V55208
System infrastructure / Enclosures and control units / Junction boxes / Surface mounting

IP56 junction box 240x190x90mm
Surface mounting junction box with undrilled walls, blind cover closed with stianless steel screws, RAL 7035 grey. Dimensions 240x190x90 mm

Product Status
3 - Active

Class group
Connection material (electrotechnical)
Class
Box/housing for surface mounting on the wall/ceiling
Max. conductor cross section
0
Equipped with
None
Shape
Rectangular
Mounting method
Wall-/ceiling mounting
Mounting in the soil
No
Mounting under water
No
For tube diameter
20/25 mm
Inlet from the rear
No
Length
240,00 mm
Width
265,00 mm
Depth
96,00 mm
Diameter
0 mm
Tackable
No
Number of inlets
0
Type of housing feed-through
None
Material
Plastic
Halogen free
No
Surface protection
Untreated
Colour
Grey
Degree of protection (IP)
IP56
Cover model
Blind cover
Transparent cover
No
Cover attachment
Screwed
Castable
No
With casting compound
No
Sealable
No
Rated insulation voltage Ui
450 V
Circuit integrity
None
With screening
No
Weatherproof
Yes
Operating temperature
0 - 60 °C
Explosion-tested version
No
For Ex-zone gas
None
For Ex-Zone dust
None

00. CE Marking - EU

01. IMQ - Italy

96. Electrotechnical expert

Minimum order quantity: 12 NR

Barcode

Barcode Qty 1 NR
8007352079748
1 NR
25x19.7x9.6 [cm]
569 [g]
Barcode Qty 12 NR
8007352473423
12 NR
59x47x41 [cm]
7,620 [g]
