IP44 junction box 80x80x40mm

Pdf

Vimar - V55003 - IP44 junction box 80x80x40mm

V55003
System infrastructure / Enclosures and control units / Junction boxes / Surface mounting

IP44 junction box 80x80x40mm
Surface mounting junction box with cable entries, snap closed cover, RAL 7035 grey. Dimensions 80x80x40 mm

Product Status
3 - Active

Class group
Connection material (electrotechnical)

Class
Box/housing for surface mounting on the wall/ceiling

Max. conductor cross section
0

Equipped with
None

Shape
Square

Mounting method
Wall-/ceiling mounting

Mounting in the soil
No

Mounting under water
No

For tube diameter
20/25 mm

Inlet from the rear
No

Length
80,00 mm

Width
103,00 mm

Depth
44,00 mm

Diameter
0 mm

Tackable
No

Number of inlets
6

Type of housing feed-through
Trimmable step membrane

Material
Plastic

Halogen free
No

Surface protection
Untreated

Colour
Grey

Degree of protection (IP)
IP44

Cover model
Blind cover

Transparent cover
No

Cover attachment
Screwed

Castable
No

With casting compound
No

Sealable
No

Rated insulation voltage Ui
450 V

Circuit integrity
None

With screening
No

Weatherproof
Yes

Operating temperature
0 - 60 °C

Explosion-tested version
No

For Ex-zone gas
None

For Ex-Zone dust
None

00. CE Marking - EU

01. IMQ - Italy

96. Electrotechnical expert

Minimum order quantity: 6 NR

Barcode

8007352077003

1 NR

10.4x10.4x4.4 [cm]

71 [g]

8007352077010

6 NR

10.4x10.4x26.5 [cm]

428 [g]

8007352115712

54 NR

38.5x29x30 [cm]

4,400 [g]

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
