Flush-mount box f/hollow walls f/V53154 - V53754

Pdf
Vimar - V53754 - Flush-mount box f/hollow walls f/V53154
Vimar - V53754 - Flush-mount box f/hollow walls f/V53154

V53754
System infrastructure / Enclosures and control units / Switchboards / Flush mounting

Flush-mount box f/hollow walls f/V53154
Flush mounting box for 54-module consumer unit (GW 650 °C) for hollow walls, light blue. Dimensions 426x588x100 mm

Product Status
3 - Active

Class group
Distribution boards
Class
Empty cabinet
Mounting method
Flush-mounted
Type of covering
None
Cover model
None
Type of door
None
Transparent cover/door
No
With lock
No
Nominal current (In)
0 A
Height
588 mm
Width
426 mm
Depth
100,00 mm
Built-in depth
100,00 mm
Inner depth
98,00 mm
Colour
Other
RAL-number
0
Number of modules
54
Number of rows
3
Width in number of modular spacings
54
Number of openings for flange plates
0
Extension possible
No
Number of conduit inlets
50
Housing material
Plastic
Surface protection
Untreated
With mounting plate
No
Suitable for outdoor use
No
Suitable for lightning protection
No
Degree of protection (IP)
IP40
Protection class
II
Circuit integrity
None

01. IMQ - Italy

96. Electrotechnical expert

Minimum order quantity: 3 NR

Barcode

Barcode Qty 1 NR
8007352510074
1 NR
38.5x58.5x10 [cm]
1,436 [g]
Barcode Qty 3 NR
8007352510081
3 NR
58.5x31x43 [cm]
5,290 [g]
