IP40 flush consumer unit 12M +door white - V52412

Pdf
Vimar - V52412 - IP40 flush consumer unit 12M +door white
Vimar - V52412 - IP40 flush consumer unit 12M +door white

V52412
System infrastructure / Enclosures and control units / Switchboards / Flush mounting

IP40 flush consumer unit 12M +door white
Flush mounting consumer unit with vertically hinged transparent door, 12 modules, RAL 9003 white

Product Status
2 - Will be discontinued

Class group
Distribution boards
Class
Small distribution board
Mounting method
Flush-mounted
Number of rows
1
Width in number of modular spacings
12
Type of covering
Door
Cover model
Closed
Transparent cover/door
Yes
With lock
No
Housing material
Plastic
Built-in depth
72,00 mm
Inner depth
92,00 mm
DIN-rail
Yes
With mounting plate
No
Extension possible
No
EMC-version
No
Colour
White
RAL-number
0
Degree of protection (IP)
IP40
Height
185,00 mm
Width
285,00 mm
Depth
93,00 mm

01. IMQ - Italy

96. Electrotechnical expert

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352152717
1 NR
28.4x18.3x9.3 [cm]
591.4 [g]
Barcode Qty 20 NR
8007352152724
20 NR
59x47x40 [cm]
12,878 [g]
