Two simple push buttons - R19520

Pdf
Vimar - R19520 - Two simple push buttons
Vimar - R19520 - Two simple push buttons

R19520
Smart systems&products / By-me Plus / ARKÉ / Devices

Two simple push buttons
Spare control device with two simple push buttons, to be completed with 1 or 2 module interchangeable buttons - 2 modules

Product Status
3 - Active

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
2
Number of modules (module system)
200
Number of poles
0
Nominal voltage
29 V
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Label space/information surface
Yes
Imprint
None
Suitable for degree of protection (IP)
IP40
Device width
44,80 mm
Device height
49,00 mm
Device depth
36,10 mm

00. CE Marking - EU

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352617278
1 NR
11.2x9.6x9.8 [cm]
98.7 [g]
