Digibus additional power supp. unit 230V - 6946

6946
ELVOX Door entry system / Digibus video entry system / Shared A/V components / System components

Digibus additional power supp. unit 230V
Additional power supply unit for Digibus video door entry system with outputs 12 Vd.c., 13.5 Vd.c., 15 V and 18 Vd.c., power supply 230 V~, for use in Digibus building complex type systems with non-digital secondary video entrance panels, installation on DIN rail (60715 TH35), occupies 12 modules size 17.5 mm

Product Status
2 - Will be discontinued

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Installer manual (359 kb)

Class group
Communication technique

Class
Power supply door communication

Application
Other

Input voltage
230 V

Type of current
DC

Output voltage
12,00 V

Degree of protection (IP)
IP20

Installation technique
Multi-wire system

Integrated door opening circuit
No

Control function
No

Evaluation function
No

Service indication
No

Mounting method
Other

Programming lock
No

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8013406149619

1 NR

22.8x12.6x9.6 [cm]

1,641 [g]
