8-ch.NVR PoE 6Mpx H.265s HDD 1TB NDAA - 46NVR.08PSN

Pdf
Vimar - 46NVR.08PSN - 8-ch.NVR PoE 6Mpx H.265s HDD 1TB NDAA
Vimar - 46NVR.08PSN - 8-ch.NVR PoE 6Mpx H.265s HDD 1TB NDAA

46NVR.08PSN
Safety / ELVOX CCTV / IP / NVR

8-ch.NVR PoE 6Mpx H.265s HDD 1TB NDAA

Product Status
3 - Active

You may also be interested in

46925.030
46925.030 - Professional HDD SATA 3,5in 3TB f/DVR
46936.001
46936.001 - USB alarm extension
Class group
Alarm installations, emergency call and signalling
Class
Matrix memory for video surveillance system
Recording type
Digital
Device construction
Desktop
Max. number of video inputs
8
Max. number of control inputs
0
With video motion detector
Yes
With DVD
No
Redundant power supply
No
Power consumption
9 W
Max. data transmission rate
100
Processor type
Other
Number of ports LAN
1
Number of ports 1000 Mbps Mini GBIC
0
Number of combination-ports RJ45/Mini GBIC
0
Number of ports PoE
8
Max. PoE power
72 W
Power over Ethernet (PoE)
802.3 at (PoE+)
Operating system
Other
Number of pre-licensed cameras
8
Number of hard disc bays
1
Number of preinstalled hard discs
1
Memory capacity per hard disc
10
RAID 0 capable
No
RAID 1 capable
No
RAID 5 capable
No
RAID 6 capable
No
RAID 10 capable
No
Hot-swappable hard disk capability
No
Width
269 mm
Height
52 mm
Depth
380 mm

00. CE Marking - EU

37. Marking - Morocco

45. NDAA compliant

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352742765
1 NR
29.5x36.5x9 [cm]
1,850 [g]
