5-port Ethernet switch Gigabit 4 PoE at - 46260.5P.02

Pdf
Vimar - 46260.5P.02 - 5-port Ethernet switch Gigabit 4 PoE at
Vimar - 46260.5P.02 - 5-port Ethernet switch Gigabit 4 PoE at

46260.5P.02
Safety / ELVOX CCTV / IP / Networking

5-port Ethernet switch Gigabit 4 PoE at
Fast Ethernet switch with 5 10/100/1000 Mbps auto-sensing ports, auto MDI/MDI-X, working LED , 4 PoE Standard IEEE 802.3af/at (End-Span 1/2+ ,3/6-) + 1 Uplink ports. Supported with 10/100/1000 BASE-T, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3X standards, MAC 2K table. Power supply 54 Vdc 1,11 A, power unit included. Dimensions: 135x86x27 mm

Product Status
3 - Active

Sheets, Manuals, Documentation

Class group
Data and telecommunication
Class
Network switch
Ethernet
Yes
Number of ports 10/100 Mbps RJ45
0
Number of ports 10/100/1000 Mbps RJ45
5
Number of ports 1000 Mbps RJ45
5
Number of ports 10 Gbps RJ45
0
Number of ports 10 Gbps Mini GBIC
0
Number of ports 100/1000 Mbps Mini GBIC
0
Number of ports 1000 Mbps Mini GBIC
0
Number of ports 40 Gbps Mini GBIC
0
Number of ports 100 Gbps Mini GBIC
0
Number of combination-ports RJ45/Mini GBIC
0
Number of ports 1000 Mbps GBIC
0
Number of ports 10/100 Mbps M12
0
Number of ports 100 Mbps SC
0
Number of ports 1000 Mbps SC (SX)
0
Number of ports 1000 Mbps SC (LX)
0
Number of ports 100 Mbps ST
0
Number of ports 100 Mbps POF
0
Number of ports 1000 Mbps POF
0
Number of other ports
5
Power over Ethernet (PoE)
802.3 at (PoE+)
Number of ports PoE
4
Max. PoE power
60 W
Max. power consumption
5 W
Redundant power supply
No
Mounting method
Desk type
Manageable
No
Degree of protection (IP)
Other
Height
27,00 mm
Width
135,0 mm
Depth
86,00 mm
Compatible with Grade2TV according to XP-C 90-483
No
Compatible with Grade3TV according to XP-C 90-483
No

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8013406307194
1 NR
21x13x8.5 [cm]
798.5 [g]
Barcode Qty 20 NR
8013406307378
20 NR
45x35x35 [cm]
16,620 [g]
