IP Speed Dome cam-2Mpx 15x 200m IR Plus - 46235.015B

Pdf
Vimar - 46235.015B - IP Speed Dome cam-2Mpx 15x 200m IR Plus
Vimar - 46235.015B - IP Speed Dome cam-2Mpx 15x 200m IR Plus

46235.015B
Safety / ELVOX CCTV / IP / Cameras

IP Speed Dome cam-2Mpx 15x 200m IR Plus

Product Status
3 - Active

You may also be interested in

46917.002.01
46917.002.01 - Pole bracket for IP Bullet/SpeedDome
46918.201
46918.201 - Ceiling bracket for Speed Dome IP 20x
46264.002
46264.002 - Protection for PoE RJ45 Ethernet
Class group
Alarm installations, emergency call and signalling
Class
Camera for surveillance system
Model
Standard (Fixed)
Mounting method
Wall
Scope of application
Universal
Transmission
Other
Protocol
TCP/IP
Power over Ethernet (PoE)
802.3 at (PoE+)
Picture system
PAL
Property picture system
Colour
Focal size
5,00 - 75,00 mm
Colour
White
Wireless
No
Type of interface
Other
Number of pixels (Megapixel)
2
Memory capacity
256
With lens
Yes
With IR lamp
Yes
Max. infrared reach
150 m
Number of digital inputs
0
Number of digital outputs
0
Number of audio inputs
0
Number of audio outputs
0
Vandal proof
No
Impact strength
None
With video motion detector
Yes
Degree of protection (IP)
IP66
Horizontal field of view
4,00 - 54,00
Power consumption
22,00 W
Supply voltage
0,10 - 12,01 V
Voltage type
DC
Diameter
173,00 mm
Height
247,00 mm
Width
173,00 mm
Depth
247,00 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
ONVIF-compliant
Yes

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352679153
1 NR
32x39x22 [cm]
3,800 [g]
