40174
ELVOX Door entry system / Video entry outdoor stations / Shared A/V components / Push buttons
4 buttons kit for entrance plate 40170
Product Status
3 - Active
Sheets, Manuals, Documentation
- Additional instruction sheet (1673 kb)
- Quick Guide (4779 kb)
- Manual do instalador (4176 kb)
- Manuale installatore (4171 kb)
- Manuel installateur (4177 kb)
- Manual del instalador (4159 kb)
- Installer manual (4184 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (4174 kb)
- Installationsanleitung (4185 kb)
- دليل القائم بالتركيب (4059 kb)
- Label printer module for entrance panels (1640 kb)
Drawings
Class group
Communication technique (components and systems)
Communication technique (components and systems)
Class
Mounting frame for door station
Mounting frame for door station
Material
Plastic
Plastic
Colour
White
White
Mounting method
Other
Other
Width
86,00 mm
86,00 mm
Height
14,80 mm
14,80 mm
Depth
6,40 mm
6,40 mm
Minimum order quantity: 1 NR
Barcode

8007352745049
1 NR
8.6x6x0.64 [cm]
22.39 [g]

8007352745056
12 NR
10x7.8x7.6 [cm]
283.21 [g]

8007352745063
120 NR
24x17x19 [cm]
3,571.73 [g]
