32134.G
Smart systems&products / KNX / LINEA / XT devices
Device XT KNX Advanced 1M 4label black
Linea control device with XT platform, KNX standard with 4 independent push buttons customisable with labels, proximity function, labels with status function and visible in darkness with brightness control, black - 1 front module
Product Status
3 - Active
Sheets, Manuals, Documentation
- Light multilanguage instructions sheet (1426 kb)
- Foglio istruzioni Full (1026 kb)
- Notice technique Full (1029 kb)
- Ficha de instrucciones Full (1029 kb)
- Full instructions sheet (1027 kb)
- Φυλλάδιο οδηγιών Full (1139 kb)
- Anweisungsblatt Full (1029 kb)
- ورقة الإرشادات Full (1062 kb)
- Manuale installatore (2922 kb)
- Installer manual (1901 kb)
Product Software
Drawings
Class group
Installation bus systems
Installation bus systems
Class
Multi operating device for bus system
Multi operating device for bus system
Mounting method
Flush-mounted
Flush-mounted
Number of actuation points
4
4
Status-LED
Yes
Yes
IR sensor
Yes
Yes
Manual set point setting
Yes
Yes
Central functional unit for senders/actuators
Yes
Yes
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
Black
Black
RAL-number (similar)
7032
7032
Transparent
No
No
Degree of protection (IP)
IP40
IP40
With bus connection
Yes
Yes
Minimum order quantity: 1 NR
Barcode

8007352736573
1 NR
11.5x6x1.7 [cm]
36.8 [g]

8007352736580
10 NR
13x9.4x12.6 [cm]
429 [g]
