32124.G
Smart systems&products / KNX / LINEA / XT devices
Device XT KNX Advanced 1M 4-point black
Linea control device with XT platform, KNX standard with 4 independent push buttons, proximity function, LED with status function and visible in darkness with brightness control, black - 1 front module
Product Status
3 - Active
Sheets, Manuals, Documentation
- Light multilanguage instructions sheet (1186 kb)
- Foglio istruzioni Full (840 kb)
- Notice technique Full (842 kb)
- Ficha de instrucciones Full (841 kb)
- Φυλλάδιο οδηγιών Full (955 kb)
- Anweisungsblatt Full (841 kb)
- ورقة الإرشادات Full (873 kb)
- Full instructions sheet (840 kb)
- Manuale installatore (2922 kb)
- Installer manual (1901 kb)
Product Software
Drawings
Class group
Installation bus systems
Installation bus systems
Class
Multi operating device for bus system
Multi operating device for bus system
Mounting method
Flush-mounted
Flush-mounted
Number of actuation points
4
4
Status-LED
Yes
Yes
IR sensor
Yes
Yes
Manual set point setting
Yes
Yes
Central functional unit for senders/actuators
Yes
Yes
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
Black
Black
RAL-number (similar)
7021
7021
Transparent
No
No
Degree of protection (IP)
IP40
IP40
Minimum order quantity: 1 NR
Barcode

8007352736610
1 NR
11.5x6x1.7 [cm]
32.95 [g]

8007352736627
10 NR
13x9.4x12.6 [cm]
388 [g]
