Axial button 1M arrow symbol black - 31000A.FG

Pdf
Vimar - 31000A.FG - Axial button 1M arrow symbol black
Vimar - 31000A.FG - Axial button 1M arrow symbol black

31000A.FG
Wiring devices / Traditional wiring devices / LINEA / Buttons

Axial button 1M arrow symbol black
1-module interchangeable button for axial controls, lightable arrows symbol, black

Product Status
3 - Active

You may also be interested in

30804
30804 - IoT roller shutter control mechanism

Drawings

view encumbered art. 31000A.FG
PNG DXF
rear view art. 31000A.FG
PNG DXF
3D view art. 31000A.FG
PNG DXF
Class group
Domestic switching devices
Class
Control element/cover plate for domestic switching devices
Model
Other
Imprint/indication
Symbol ˝arrows˝
Scannable symbol/barrier free
No
Utilization
Switch/push button
Suitable for touch sensor connector for bus system
No
Type of fastening
Engage (snap)
Monitoring window/light outlet
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Anti-bacterial treatment
No
Colour
Black
RAL-number (similar)
7021
With label area
No
With exchangeable lens/symbol
No
Suitable for degree of protection (IP)
IP40
Width
2.210,00 mm
Height
5.270,00 mm
Depth
530,00 mm

00. CE Marking - EU

01. IMQ - Italy

96. Electrotechnical expert

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352693364
1 NR
10x5x1.5 [cm]
3.8 [g]
Barcode Qty 20 NR
8007352693371
20 NR
19.8x11.5x6.8 [cm]
143.6 [g]
Barcode Qty 160 NR
8007352693388
160 NR
36x22.5x19.5 [cm]
1,440 [g]
