Anti-theft support 7M + screws - 30617AE

Pdf
Vimar - 30617AE - Anti-theft support 7M + screws
Vimar - 30617AE - Anti-theft support 7M + screws

30617AE
Wiring devices / Traditional wiring devices / LINEA / Mounting frames

Anti-theft support 7M + screws
7-module anti-tamper mounting frame, with screws, for 6/7-module mounting boxes

Product Status
3 - Active

Drawings

view encumbered art. 30617AE
PNG DXF
rear view art. 30617AE
PNG DXF
3D view art. 30617AE
PNG DXF
Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
With nail
No
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
7
Number of modules vertical (module system)
0
With built-in installation box
No
With screws
No
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated

00. CE Marking - EU

01. IMQ - Italy

96. Electrotechnical expert

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352729605
1 NR
20x7.9x2.6 [cm]
62.7 [g]
Barcode Qty 10 NR
8007352729612
10 NR
28.6x24.8x9.6 [cm]
627 [g]
