Diebstahlsicherung 4M + Schrauben - 30614AE

30614AE
Wiring devices / Traditional wiring devices / LINEA / Mounting frames

Diebstahlsicherung 4M + Schrauben
4-module anti-tamper mounting frame, with screws, for 4-module mounting boxes

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with screw

With nail
No

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
4

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

00. CE Marking - EU

01. IMQ - Italy

96. Electrotechnical expert

Minimum order quantity: 10 NR

---

Barcode

8007352729629

1 NR

14x7.8x1.9 [cm]

43.5 [g]

8007352729636

10 NR

28.4x18.4x13.7 [cm]

435 [g]
