4-button KNX control 2M - 30580

Pdf
Vimar - 30580 - 4-button KNX control 2M
Vimar - 30580 - 4-button KNX control 2M

30580
Smart systems&products / KNX / LINEA / Devices

4-button KNX control 2M
Control device with four push buttons, KNX standard, RGB LED visible in darkness with brightness control, to be completed with two 1- or 2-module interchangeable half-button caps - 2 modules

Product Status
3 - Active

You may also be interested in

31480.G
31480.G - 2 half buttons 1M w/o symbol cust.black
31480.B
31480.B - 2 half buttons 1M w/o symbol cust.white
31480.C
31480.C - 2 half butt. 1M w/o symbol cust. canvas
31480.2G
31480.2G - 2 half buttons 2M w/o symbol cust.black
31480.2B
31480.2B - 2 half buttons 2M w/o symbol cust.white
31480.2C
31480.2C - 2 half buttons 2M w/o symbol cust.canvas
Class group
Installation bus systems
Class
Multi operating device for bus system
Bus system KNX
Yes
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Mounting method
Flush-mounted
Width in number of modular spacings
2
Number of actuation points
4
With display
No
Status-LED
Yes
IR sensor
No
Manual set point setting
No
Presence button
No
With temperature controller
No
With integrated DCF77 receiver
No
With time switch clock
No
With anti-theft/dismantling protection
No
Central functional unit for senders/actuators
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Black
RAL-number (similar)
7021
Transparent
No
Degree of protection (IP)
IP40
With bus connection
Yes

00. CE Marking - EU

27. KNX

37. Marking - Morocco

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352679757
1 NR
6x4.5x5.4 [cm]
36.8 [g]
Barcode Qty 72 NR
8007352679771
72 NR
37.5x30x13.5 [cm]
2,980 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
