Bluetooth Low Energy control - 30504

Pdf
Vimar - 30504 - Bluetooth Low Energy control
Vimar - 30504 - Bluetooth Low Energy control

30504
Smart systems&products / Smart switch&sound / LINEA / Non-modular components

Bluetooth Low Energy control
Flat control with four push buttons with 2.4 GHz radio frequency transmitter, Bluetooth Low Energy standard, energy harvesting power supply provided by the built-in electro-dynamic generator, to be completed with dedicated buttons 31506 or 31506.2 - 2 modules

Product Status
3 - Active

You may also be interested in

31506.B
31506.B - Radio control button 1M white 2pc
31506.2B
31506.2B - Radio control button 2M white
31506.G
31506.G - Radio control button 1M black 2pc
31506.2G
31506.2G - Radio control button 2M black
31506.C
31506.C - Radio control button 1M canvas 2pc
31506.2C
31506.2C - Radio control button 2M canvas
30507.G
30507.G - Radio control frame 2M black
30507.B
30507.B - Radio control frame 2M white
Class group
Installation bus systems
Class
Light control unit for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Radio frequent bidirectional
No
Mounting method
Surface mounted
Width in number of modular spacings
2
With bus connection
No
Substation input
No
Local operation/hand operation
No
With LED indication
No
Interface 1-10 V
No
Number of inputs for light sensor
0
Max. switching current (resistive load)
0 A
Number of outputs
4
Max. control current
0 mA
Degree of protection (IP)
IP40

00. CE Marking - EU

37. Marking - Morocco

40. Bluetooth technology

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352694156
1 NR
6x4.5x5.4 [cm]
34.98 [g]
Barcode Qty 10 NR
8007352694163
10 NR
23.5x12.5x6.5 [cm]
429.64 [g]
Barcode Qty 90 NR
8007352694170
90 NR
37.5x30x21 [cm]
4,265 [g]
