4-button control+dimmer 0/1-10V 2M - 30489

Pdf
Vimar - 30489 - 4-button control+dimmer 0/1-10V 2M
Vimar - 30489 - 4-button control+dimmer 0/1-10V 2M

30489
Smart systems&products / By-me Plus / LINEA / Devices

4-button control+dimmer 0/1-10V 2M
By-me Plus home automation control device with four push buttons, 1 0/1-10 V SELV output, 1 NO contact relay output 2 A 120-240 V~ 50/60 Hz for ballast and LED driver, RGB LED visible in darkness with brightness control, to be completed with 1- or 2-module interchangeable half-button caps - 2 modules

Product Status
3 - Active

You may also be interested in

31480.RG
31480.RG - 2 half buttons 1M control black
31480.RB
31480.RB - 2 half buttons 1M control white
31480.RC
31480.RC - 2 half buttons 1M control canvas
31480.2RG
31480.2RG - 2 half buttons 2M control black
31480.2RB
31480.2RB - 2 half buttons 2M control white
31480.2RC
31480.2RC - 2 half buttons 2M control canvas
Class group
Installation bus systems
Class
Multi operating device for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Mounting method
Flush-mounted
Width in number of modular spacings
2
Number of actuation points
4
With display
No
Status-LED
Yes
IR sensor
No
Manual set point setting
No
Presence button
No
With temperature controller
No
With integrated DCF77 receiver
No
With time switch clock
No
With anti-theft/dismantling protection
No
Central functional unit for senders/actuators
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Other
RAL-number (similar)
7024
Transparent
No
Degree of protection (IP)
IP40
With bus connection
Yes

00. CE Marking - EU

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352685840
1 NR
6x5.4x5.2 [cm]
71.8 [g]
Barcode Qty 10 NR
8007352685857
10 NR
28.1x13.1x6 [cm]
806.3 [g]
