4 ampl.button Home autom.control 1+1W 2M - 30484

Pdf
Vimar - 30484 - 4 ampl.button Home autom.control 1+1W 2M
Vimar - 30484 - 4 ampl.button Home autom.control 1+1W 2M

30484
Smart systems&products / By-me Plus / LINEA / Devices

4 ampl.button Home autom.control 1+1W 2M
Home automation control device with four push buttons and 1+1 W RMS stereo amplifier, 2 outputs for 8 ohm speakers, RGB LED visible in darkness with brightness control, to be completed with 1- or 2-module interchangeable half-button caps - 2 modules

Product Status
3 - Active

You may also be interested in

31480.TG
31480.TG - 2 half buttons 1M source/track black
31480.TB
31480.TB - 2 half buttons 1M source/track white
31480.TC
31480.TC - 2 half buttons 1M source/track canvas
31480.VG
31480.VG - 2 half buttons 1M volume ON/OFF black
31480.VB
31480.VB - 2 half buttons 1M volume ON/OFF white
31480.VC
31480.VC - 2 half buttons 1M volume ON/OFF canvas
Class group
Installation bus systems
Class
Multi operating device for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Mounting method
Flush-mounted
Width in number of modular spacings
2
Number of actuation points
4
With display
No
Status-LED
Yes
IR sensor
No
Manual set point setting
No
Presence button
No
With temperature controller
No
With integrated DCF77 receiver
No
With time switch clock
No
With anti-theft/dismantling protection
No
Central functional unit for senders/actuators
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Other
RAL-number (similar)
7024
Transparent
No
Degree of protection (IP)
IP40
With bus connection
Yes

00. CE Marking - EU

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352689459
1 NR
6x5.4x5.2 [cm]
72.6 [g]
Barcode Qty 10 NR
8007352689466
10 NR
28.1x13.1x6 [cm]
814.4 [g]
