1P+N C16 RCBO 120-230V 6mA white - 30411.166B

Pdf
Vimar - 30411.166B - 1P+N C16 RCBO 120-230V 6mA white
Vimar - 30411.166B - 1P+N C16 RCBO 120-230V 6mA white

30411.166B
Wiring devices / Traditional wiring devices / LINEA / Devices

1P+N C16 RCBO 120-230V 6mA white
1P+N C 16 residual current breaker with overcurrent protection (RCBO), 120-230 V~ 50-60 Hz, IΔn 6 mA, breaking capacity 3000 A, white - 2 modules

Product Status
3 - Active

Class group
Circuit breakers and fuses
Class
Earth leakage circuit breaker
Number of poles (total)
2
Number of protected poles
1
Rated voltage
230 V
Rated impulse withstand voltage Uimp
3 kV
Rated current
16 A
Rated fault current
16 A
Leakage current type
A
Current limiting class
1
Rated short-circuit breaking capacity according to EN 61009
3 kA
Rated short-circuit breaking capacity according to IEC 60947-2
3 kA
Rated short-circuit breaking capacity Icn according to EN 61009-1
3,00 kA
Surge current capacity
3,00 kA
Voltage type
AC
Frequency
50/60 Hz
Release characteristic
C
Concurrently switching neutral conductor
Yes
With interlocking device
No
Over voltage category
3
Built-in depth
43,80 mm
Flush-mounted installation
Yes
Anti-nuisance tripping version
No
Degree of protection (IP)
IP40
Connectable conductor cross section multi-wired
1,50 - 4,00

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352740976
1 NR
6x5.4x5.2 [cm]
97.96 [g]
Barcode Qty 10 NR
8007352740983
10 NR
28.1x13.1x6 [cm]
1,064 [g]
