MUR/DND 1M backlit switch canvas - 30408.C

Pdf
Vimar - 30408.C - MUR/DND 1M backlit switch canvas
Vimar - 30408.C - MUR/DND 1M backlit switch canvas

30408.C
Wiring devices / Traditional wiring devices / LINEA / Devices

MUR/DND 1M backlit switch canvas
1P 10 AX 250 V~ switch, with Do Not Disturb and Make Up Room symbols, canvas. Supplied with 110-250V~ LED signalling unit. Max 100 W for lamps with built-in power supply unit (IEC 60669-1:2017)

Product Status
3 - Active

Drawings

view encumbered art. 30408.C
PNG DXF
rear view art. 30408.C
PNG DXF
3D view art. 30408.C
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Rocker
Number of contacts as normally closed contact
0
Number of contacts as normally open contact
0
Number of contacts as change-over contact
0
Number of revolving contacts
0
Contactless type
No
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
Yes
With light source
Yes
With signal lamp
Yes
Feedback-signal contact
No
Connection type
Screwed terminal
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
7032
Transparent
No
Label space/information surface
No
Imprint
Other
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
52,80 mm
Device depth
30,90 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE Marking - EU

13. SNI - Indonesia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352691889
1 NR
4.6x2.7x5.6 [cm]
30.54 [g]
Barcode Qty 10 NR
8007352691896
10 NR
14.6x10x6.6 [cm]
352.84 [g]
